If i ncorrect pressure is obtained, adjust inch valve cable by perform ing
n.
the following:
Turn Star-Delta switch to Y position, then to O position.
(1)
Turn main power switch to O position.
(2)
After the main motor has stopped, remove the nut and cable on top
(3)
of the inch valve.
Adjust the adjusting nuts on the cable either down for more
(4)
pressure or up for less pressure.
Reinstall the nut and cable onto the inch valve.
(5)
(6)
Turn main power switch to I position.
Turn Star-Delta switch to Y position. After the main motor has
(7)
reached full speed, turn switch to
position.
Press in clamp pressure adjustment knob.
(8)
Repeat steps i. through n. until proper adjustments have been
(9)
obtained.
o.
Turn off power.
(1) Turn Star-Delta switch to Y position and then to O position.
(2) Turn main power switch to O position.
After the main motor has stopped, remove the manometer gage and
p.
reinstall the test fitting nut and ball.
q.
