TM 5-3610-253-14
WARNING
Electrical shock hazard. You must stand on rubber matting as a protective
measure before performing this procedure. Death or serious injury may
occur.
m.
Locate the TAM circuit board and change the dial readings to the new
number obtained in step k. or l.
n.
Repeat steps f. - l., decreasing the cut by a whole number each time
until proper adjustment is obtained.
o.
Turn off power.
(1) Turn Star-Delta switch to Y position, then to O position.
(2) Turn main power switch to O position.
(3) Using operator key, lock the safety lock.
Reinstall front electronics enclosure cover.
p.
5-40.61 Adjust
Safety Bolt
Proximity Switches (SB.A and
SB.E).
MOS: 35E, Special Electronic Devices Repairer
TOOLS: Flat Tip Screwdriver
13 mm Combination Wrench
Metric Feeler Gage (0.8 mm)
WARNING
Death or serious injury may occur from electrical shock unless power is
turned off before servicing.
a.
Turn off power.
(1) Turn Star-Delta switch to Y posi tion, then to O position.
(2) Turn main power switch to O posi tion.
(3) Using operator key, lock safety lock and keep key in your
5-636
